High precision pressurization / heating Gangbonder

Specifications
  • Stage size : 100 x 100 mm
  • Die size : 1 x 1 mm to 20 x 20 mm
  • Head-stage parallelism : ± 3 micron / 20 mm □
      ± 20 micron / 100 mm □
  • Pressurized range : 100-5000N
  • Heating range : Max 300 ℃
  • Nitrogen purge is possible

Panel cleaning machine

Panel cleaning machine


A multi-layer rocking panel pure water washer. It supports sizes up to about 12 inches.


O2 plasma cleaning machine

MPS-01 (D&T)


Basic specifications

ACF bonding machine

ASG M3BC


Basic specifications

FOG bonding machine

F-20


Basic specifications
  • Corresponding panel dimensions: 5 inches
  • Bonding length: 55mm
